Hundredstar-made Vehicles Portal (wip)

by **Hundredstar** » Thu Oct 03, 2019 7:08 pm

The T-20B 105mm Light Weapon is an air-transportable 105mm caliber towed howitzer planning for fast response firepowers such as paratroopers. It entered benefit within the Hundredstarian Armed force in 2015 (T-20A). It saw combat in 2016 amid the Bristen Faults conflict. Firing at the Line-of-Sight incorporates the greatest run of 800 meters and Beyond the Line-Of-Sight up to 17,200 meters. The Hundredstarian Armed force is upgrading its existing tall portability 105mm Light Weapons to keep the weapon framework in dynamic benefit until 2025 utilizing T-20B. The Capability Improvement Program centers on weight diminishment, improvements to its laser situating framework (Warhammer Program) for made strides precision, and incorporation of a modern family of improved ammo.

Crew: 6

Dimensions
Height: 2.10 meter
Length: 8.80 meter

Main Gun Caliber: 105 millimeter
Width: 1.80 meter

Performance
Main Gun Max Range: 17,200 meter (10.7 mile)
Max Rate of Fire: 6 roundperminute

Max Weight: 1,900 kilogram

by **Hundredstar** » Fri Oct 04, 2019 1:41 am

The ART-155B7 is a 155 mm towed howitzer produced by GACO Land System, a Hundredstarian military manufacturer. It is helicopter-transportable, reliable and more available over its predecessor (B6). It can hit targets at 22 km employing conventional ammunition and at 30 km with assisted ammunition.

Armament
Gun bore 155 mm
Barrel length 52 calibers
Projectile weight (HE) 43.5 kg
Maximum range of fire 24 - 30 km
Maximum rate of fire 6 rpm
Sustained rate of fire 2 rpm
Elevation range - 5 to + 70 degrees
Traverse range 56 degrees

Dimensions and weight
Weight 6.9 t
Length (in travelling order) 9.8 m
Length (in combat order) 12.43 m
Width (in travelling order 2.58 m
Width (in combat order) 7.5 m

by **Hundredstar** » Fri Oct 04, 2019 2:29 pm

4x4 variant

Fully-cab variant

The main task of the Militia is to give troops with logistical and utility support. Also, there are some dedicated versions of this vehicle such as Field Ambulance, Radar transporter or weather-gathering vehicle. It is a purpose-designed military vehicle, which can function in tough conditions. It has good cross-country mobility and can travel over difficult terrain. The Militia has a payload capacity and size of a light truck. However, due to its military nature, the Militia can withstand intense use or even abuse, far exceeding that of militarized commercial vehicles or those based on commercial drivelines. Most versions of the Militia can carry loads with a maximum weight of 2 400-5 000 kg. This military vehicle can also tow trailers and 105mm light artillery pieces.

There are 2-, 3- or 4-door versions of the Militia. All versions can be armored. The armored cab provides fortification for the passengers against small arms fire and artillery shell splinters, mines and improvised explosive devices. The Militia can be prepared with a number of other protection elements, such as smoke grenade dischargers, fire suppression systems, protective net against anti-tank rocket launchers, and even the NBC protection system, though this equipment is optional. The Militia can be fitted with a battlefield management system.

Dimensions and weight
Weight (empty) 8 - 9.5 t
Payload capacity 2.4 - 5 t
Length 6.9 m
Width 2.3 m
Height 2.1 m

Mobility
Engine Radimes RM-300i diesel
Engine power 296 hp
Maximum road speed 110 km/h
Range 600 - 650 km

by **Hundredstar** » Fri Oct 04, 2019 3:40 pm

Radimes Stronghold 6x6
This military truck has a straight layout, with a front-mounted engine and a forward driver cab. A baseline version of the Stronghold has a general troop/cargo body with folding-down sides and tailgate. Its cargo area is covered with removable bows and canvas cover. Nevertheless, this military truck is also offered with a number of body styles. Its payload on cross-country terrain is limited to 6 t. Load with 6 t of cargo the Stronghold has a maximum road speed of 85 km/h. It can also tow trailers or artillery pieces with a maximum weight up to 7 t. An all-metal cab provides seating for driver and two passengers. The Stronghold is power-driven by a Radimes RM-350i 10.85-liter V8 diesel engine, developing 310 hp. This military truck is en suite with a central tire pressure system, which improves off-road mobility. A self-recovery winch was fitted to some models. A number of features are included into the design of the truck to cope with the unforgiving operating conditions found in the global environment, and without modification these trucks are designed to operate throughout between -45°C to +50°C, in relative humidity up to 98% at +25°C, and at altitudes of up 4,500m.

Dimensions and weight
Weight (empty) ~ 7 t
Payload capacity 6 t
Length ~ 7.4 m
Width ~ 2.5 m
Height ~ 3 m

Mobility
Engine Radimes RM-350i 10.85-liter V8 diesel engine
Engine power 310 hp
Maximum road speed 85 km/h
Range ~ 1 000 km

by **Hundredstar** » Sun Oct 06, 2019 3:33 pm

Excard Wita multipurpose van

User
- Greater Cebu

by **Hundredstar** » Sun Oct 06, 2019 6:40 pm

The SPH-930 Landgrab is equipped with a turret-mounted 155 mm/L39 howitzer, built-in with a semi-automatic loading system. A semi-automatic loading system allows operation with 4 men crew. The SPH-930 is well-suited with all standard NATO munitions. It fires HE, extended-range HE, smoke and illumination projectiles. A home-grown GACO Land System 155 mm cargo round can also be fired. The HE projectile has a maximum range of about 19 km and the extended range projectile of 30 km.

The SPH-930 Landgrab has a maximum rate of fire of 6 rounds per minute. It can also make a burst of fire of three rounds in 20 seconds, which gives a shoot-and-scoot capability. It takes less than 60 seconds to arrange a vehicle for firing and 40 seconds to leave firing position. SPH-930 Landgrab is fitted with a modern fire control system, which includes an on board positioning and navigation system. It can obtain target information form command post or forward observers via satellite or Ultra-speed broadband data link. It also bids high fire accuracy. It is claimed that Armor of the SPH-930 Landgrab provides protection against 7.62 mm Armor-piercing rounds and artillery shell fragments. Vehicle is fitted with an automatic fire suppression system. The Landgrab is powered by the Radimes RM600i12 diesel engine, developing 550 horsepower.

Dimensions and weight
Weight 28.3 t
Length (gun forward) 10.21 m
Hull length 6.6 m
Width 3 m
Height 3.28 m

Armament
Main gun 155 mm howitzer
Barrel length 39 calibers
Machine guns 1 x 7.62 mm
Maximum firing range 30 km
Maximum rate of fire 6 rpm

Mobility
Engine Radimes RM600i12 diesel engine
Engine power 550 hp
Maximum road speed 50 km/h
Range 350 km

by **Hundredstar** » Sun Oct 06, 2019 11:10 pm

GACO-Heliux T-100 Sprinter is a subsonic, single-engine, tandem two-seat, training/light attack aircraft to meet the requirements of the global needs for a light training aircraft. It is powered by a fuel-efficient Heliux F-2021A turbofan engine. In addition to training, T-100 provides limited ground attack capability.

T-100 also equip with Specktra-100 Manpad Threat Avoidance System. Specktra-100 is an aircraft-mounted Directional Infrared Counter Measure (DIRCM) system developed in cooperation between Gigatone and XDR Technologies. The Specktra-100's laser system is capable of neutralizing all exiting types of infrared seekers in a multiple threats scenario. Its unique laser emits a high-energy beam in the spectral range of infrared emissions from the aircraft and missile seeker.

GACO-Heliux T-100 Sprinter includes a low-powered turbofan of good fuel economy, tandem stepped seating with Dresslar Technology zero/zero seats, manual controls apart from powered ailerons, and a large bay in the belly into which can be fitted a range of weapon systems.

Dimensions and weight
Length 12.25 m
Wing span 10.6 m
Height 4.25 m
Weight (empty) 3.3 t
Weight (maximum take off) 5.6 t

Engines and performance
Engines 1 x Heliux F-2021A turbofan
Traction (dry / with afterburning) 15.57 kN
Maximum speed 793 km/h
Ferry range 3 613 km
Combat radius 380 km

Armament
Cannon 1 x 30 mm DEFA cannon or two 12.7 mm machine guns
Bombs up to 1 000 kg of bombs
Other rocket pods

by **Hundredstar** » Tue Oct 08, 2019 9:16 pm

by **Hundredstar** » Wed Oct 09, 2019 11:26 pm

by **Hundredstar** » Thu Oct 10, 2019 3:00 pm

by **Hundredstar** » Fri Oct 11, 2019 10:59 am

by **Hundredstar** » Mon Oct 14, 2019 5:55 am

by **Hundredstar** » Mon Oct 14, 2019 11:09 pm

by **Hundredstar** » Wed Oct 16, 2019 5:07 am

PROJECT LAND-AIR 19567: PROVIDING SHORT-RANGE TRANSPORTATION AIRCRAFT FOR ARMY

Proposal #1

Proposal #2

Proposal #3

by **Hundredstar** » Thu Oct 17, 2019 4:42 am

by **Hundredstar** » Sun Oct 20, 2019 3:44 am

by **Hundredstar** » Mon Oct 21, 2019 5:10 am

by **Hundredstar** » Thu Oct 24, 2019 6:02 am

GACO MBT-1706 Skorpion MBT

Specification
Model: GACO MBT-1706 Skorpion MBT
Developer: GACO Land System & Duke Fabrications
Crew: 3 (Commander, Gunner, Driver)
Main Armament: Kellogbearing Proving & Arsenal KPA-120HH 120 mm smoothbore gun
Autoloader: Yes (22 ready rounds in the bustle)
Secondary Armament/ Remote Weapon Station (RWS):: 1 x 7.62 mm coaxial MG, 1 x 12.7 mm RWS
Key Protection: Enhanced Armor, Project Irongates Soft-Kill APS, Mine Protection
Engine GETEN 1.5 Wombat 10-cylinder, two-stroke cycle, water-cooled diesel engine (1,500 hp)
Max Speed ~72 km/h
Transmission: GACO- Radimes Machinery automatic transmission (5 forward, 2 reverse gears).
Suspension: Hydropneumatic suspension.
Power-to-Weight Ratio: ~24.4 hp/tonne (due to increased weight).
Maximum Road Speed: ~72 km/h.
Operational Range: ~550 km (with external fuel tanks).
Combat Weight ~57 tonnes

Fire Control System & Optics
Improved FCS: The tank retains its highly accurate fire control system but receives new sights.
Commander's Sight: New third-generation Pinkus Defense EagleStar sight with advanced thermal imaging and laser rangefinder.
Gunner's Sight: New Pinkus Poxter sight from Safran, also with high-resolution thermal channels.
Digital Architecture: Fully integrated into the SCORPION-X information and combat system, allowing seamless sharing of data with other vehicles and command centers.

Dimensions & Weight
Combat Weight: ~57 tonnes
Length : (gun forward) ~9.90 meters
Hull Length: ~7.60 meters
Width : ~3.60 meters (with side skirts)
Height : (to turret roof) ~2.53 meters

Key Characteristics & Notes:
Network-Centric Warfare: The Skorpion's most defining feature is its full integration into the SCORPION-XL collaborative combat bubble. It acts as a powerful sensor and shooter node on the digital battlefield.
Commander's Role: The new sights and communication systems significantly enhance the commander's situational awareness, allowing them to manage the battlefield and coordinate with other units more effectively.

by **Hundredstar** » Thu Oct 24, 2019 6:25 pm

No.	Hull Number	Name	Construction	Commission	Yard
1	010	NJCGC Freeport	Dec 2019	May 2020	Cattickmoore
2	020	NJCGC Laneville	Dec 2019	May 2020	Pickweather Cay
3	030	NJCGC Natrona Heights	Dec 2019	May 2020	Boomerstouds
4	040	NJCGC East Deer	June 2020	Dec 2020	Cattickmoore
5	050	NJCGC Bethany	June 2020	Dec 2020	Pickweather Cay
6	060	NJCGC Scotia	June 2020	Dec 2020	Boomerstouds
7	070	NJCGC Mophie	Jan 2021	May 2021	Cattickmoore
8	080	NJCGC Butler	Jan 2021	May 2021	Pickweather Cay
9	090	NJCGC Indiana	Jan 2021	May 2021	Boomerstouds
10	011	NJCGC Fresno	June 2021	Dec 2021	Cattickmoore

by **Hundredstar** » Fri Oct 25, 2019 7:13 am

User
- Greater Cebu

by **Hundredstar** » Sat Oct 26, 2019 12:50 am

User
- Hundredstar
- Greater Cebu

by **Hundredstar** » Sat Oct 26, 2019 5:32 pm

Specification
GACO Aviation AC-746A Diamond
Engines: 2 X Heliux FF651T Turbofan.
Total thrust: 130000 hp
Speed: 870 Km/h
Range: 2100 Km
Crew: 2
Passengers: 75
Empty weight: 22490 Kg

by **Hundredstar** » Sat Oct 26, 2019 9:02 pm

User
- Hundredstar
- Greater Cebu

by **Hundredstar** » Mon Oct 28, 2019 2:32 am

Num.	Hull Number	Name	Class	Construction	Commissioned	Yard
1	F-11	JSN Uyuri	Uyuri-class FFG	Jan 2020	Dec 2020	Barwillow
2	F-12	JSN Yuha	Uyuri-class FFG	Jan 2020	Dec 2020	Cattickmoore

Num.	Hull Number	Name	Class	Construction	Commissioned	Yard
1	F-21	JSN Ruacalu	Ruacalu-class FFG	Jan 2020	Dec 2020	Barwillow
2	F-22	JSN Jading	Ruacalu-class FFG	Jan 2020	Dec 2020	Cattickmoore
3	F-23	JSN Anar	Ruacalu-class FFG	Jan 2020	Dec 2020	Pickweather Cay
4	F-24	JSN Aksa	Ruacalu-class FFG	Jan 2020	Dec 2020	Boomerstouds

Num.	Hull Number	Name	Class	Construction	Commissioned	Yard
1	P-21	JSN Nehu	Nehu-class LMV	Jan 2020	June 2020	Barwillow
2	P-22	JSN Kajang	Nehu-class LMV	Jan 2020	June 2020	Cattickmoore
3	P-23	JSN Patak	Nehu-class LMV	Jan 2020	June 2020	Pickweather Cay
4	P-24	JSN Ranta	Nehu-class LMV	Jan 2020	June 2020	Boomerstouds
5	P-25	JSN Dusi	Nehu-class LMV	July 2020	Dec 2020	Barwillow
6	P-26	JSN Gato	Nehu-class LMV	July 2020	Dec 2020	Cattickmoore
7	P-27	JSN Agi	Nehu-class LMV	July 2020	Dec 2020	Pickweather Cay
8	P-28	JSN Basu	Nehu-class LMV	July 2020	Dec 2020	Boomerstouds
9	P-29	JSN Sani	Nehu-class LMV	Jan 2021	June 2021	Pickweather Cay
10	P-30	JSN Padan	Nehu-class LMV	Jan 2021	June 2021	Boomerstouds

by **Hundredstar** » Mon Oct 28, 2019 6:41 am
